HP ProLiant DL380 Generation9 (Gen9)
c04375627 – DA – 15034 North America — Version 7 — February 17, 2015
NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, HP recommends the use of an HP approved
configurator. Contact your local sales representative for additional information.
HP DL380 Gen9 Universal Media Bay Kit
NOTE: The HP DL380 Gen9 Universal Media bay provides front VGA and 2xUSB 2.0; plus
support for 2xSFF front drives (724864-B21) and ODD support (Not included); and can only
be located in Bay1 in either a 8SFF or 8+8SFF model.
HP DL380 Gen9 Graphics Enablement Kit
NOTE: This kit includes alternative 2 heatsinks plus 6 cables to enable GPU support. Other
limitations apply, see Graphic section for more details.
HP DL380 Gen9 High Performance Fan Kit
NOTE: This kit is required for specific Ambient temperature environments, more details
here: http://www.hp.com/go/servers/Ashrae.
NOTE: This kit is also required to support Passive GPUs.
HP DL380 Gen9 High Performance Heatsink
NOTE: These Heatsinks are already included in some processors (Included in Processors
over 120W), but can be used to reduce Fan power consumption for processors with a
standard heatsink in either high workloads, dense configurations and/or extended ambient
temperature environments, more details here: http://www.hp.com/go/servers/Ashrae.
HP DL380 Gen9 2SFF Front/Rear SAS/SATA Kit
NOTE: For 2SFF front the Universal Media Bay (724865-B21) is required.
NOTE: 2SFF in the rear is only supported with a 24SFF (CTO server or field upgraded) or
12LFF (719061-B21) model.
NOTE: 2SFF Rear drives are not supported with 160W Processor
HP DL380 Gen9 3LFF Rear SAS/SATA Kit
NOTE: This is only supported in the 12LFF CTO Server (719061-B21).
NOTE: 3LFF rear drives will consume the 2nd riser expansion slot.
HP DL380 Gen9 Primary 2 Slot GPU Ready Riser Kit
Slot1: 1x Gen3 x16 FH/FL, 1xGen3 x8 FH/HL.
NOTE: This replaces the standard Primary riser in slot1.
HP DL380 Gen9 Secondary 3 Slot GPU Ready Riser Kit
Slot2: 2xGen3 x16 FH/FL, 1xGen3 x8 FH/HL
HP DL380 Gen9 8SFF Bay1 Cage/Backplane Kit
NOTE: To add an additional 8SFF drive cage in Bay1.
NOTE: To get to 16SFF total please populate bay 2 with 768857-B21 (from an 8SFF starting
point).
NOTE: This ships with 6 High Efficiency Fans.
NOTE: Selecting this option does not allow you to select the Universal Media Bay.
HP DL380 Gen9 Additional 8SFF Bay2 Cage/Backplane Kit
NOTE: To add an additional 8SFF drive cage in Bay 2. This is the optimal solution to upgrade
to 16SFF total and allows the flexibility to add the Universal Media Bay (724865-B21) for 2
additional SFF or Optical.
HP 12Gb SAS Expander Card with Cables for DL380 Gen9
NOTE: SAS expander to enable 24SFF field upgrade.
HP DL380 Gen9 Systems Insight Display Kit
NOTE: The Systems Insight Display no longer ships as standard but is available as a Factory
Integrated or field upgrade option.
Entry Processors - E5-2600v3 series Processors
HP DL380 Gen9 Intel® Xeon® E5-2603v3 (1.6GHz/6-core/15MB/85W) Processor Kit
HP DL380 Gen9 Intel® Xeon® E5-2609v3 (1.9GHz/6-core/15MB/85W) Processor Kit
Base Processors - E5-2600v3 series Processors
HP DL380 Gen9 Intel® Xeon® E5-2620v3 (2.4GHz/6-core/15MB/85W) Processor Kit
HP DL380 Gen9 Intel® Xeon® E5-2623v3 (3GHz/4-core/10MB/105W) Processor Kit
HP DL380 Gen9 Intel® Xeon® E5-2630v3 (2.4GHz/8-core/20MB/85W) Processor Kit
HP DL380 Gen9 Intel® Xeon® E5-2630Lv3 (1.8GHz/8-core/20MB/55W) Processor Kit
HP DL380 Gen9 Intel® Xeon® E5-2637v3 (3.5GHz/4-core/15MB/135W) Processor Kit
NOTE: Ships with a High Performance Heatsink.
