HP ProLiant DL380 Generation9

QuickSpecs
HP ProLiant DL380 Generation9 (Gen9)
Configuration Information - Factory Integrated Models
c04375627 – DA – 15034 North America — Version 7 — February 17, 2015
Page 18
This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP
recommends the use of an HP approved configurator. Contact your local sales representative for information on configurable product offerings and
requirements.
1. Factory Integrated Models must start with a CTO Server.
2. FIO indicates that this option is only available as a factory installable option.
3. All Factory Integrated Models will be populated with sufficient hard drive blanks based on the number of initial hard drives ordered with the server.
4. Some options may not be integrated at the factory. Contact your local sales representative for additional information.
Step 1: Base Configuration (choose one of the following configurable models)
CTO Server
HP ProLiant DL380 Gen9
8SFF Configure-to-order
Server
HP ProLiant DL380 Gen9
24SFF Configure-to-
order Server
HP ProLiant DL380 Gen9
4LFF Configure-to-order
Server
HP ProLiant DL380 Gen9
12LFF Configure-to-
order Server
SKU Number
719064-B21
767032-B21
767033-B21
719061-B21
Processor
2 (optional) x HP Smart Socket Guide
DIMM Slots
24 DIMM slots for RDIMM, LRDIMM DDR4 Memory
Storage
Controller
HP Dynamic Smart Array B140i, plus optional HP Flexible Smart Array or Smart HBA controller
PCIe
3 PCIe slots (+3 PCI slots available with upgrade option, second processor required)
Drive Cage
8SFF Hot Plug
24SFF Hot Plug
4LFF Hot Plug
12LFF Hot Plug
Network
Controller
HP Embedded 1Gb Ethernet 4-port 331i Adapter, plus optional HP Flexible LOM or stand up card
Fans
4 hot plug fans,
redundant
6 hot plug high
performance fans,
redundant
4 hot plug fans,
redundant
6 hot plug high
performance fans,
redundant
Management
iLO Management (standard), Intelligent Provisioning (standard), iLO Advanced (optional), Insight Control
(optional), HP OneView (optional)
USB
1 front, 2 internal, 2 rear
No front USB support
Ears
HP Quick Release Ears
Step 2: Choose Required Options (only one of the following from each list unless otherwise
noted)
HP Processors
Entry Processors- E5-2600v3 series Processors
HP DL380 Gen9 Intel® Xeon® E5-2603v3 (1.6GHz/6-core/15MB/85W) FIO Processor Kit
719053-L21
HP DL380 Gen9 Intel® Xeon® E5-2609v3 (1.9GHz/6-core/15MB/85W) FIO Processor Kit
719052-L21
Base Processors- E5-2600v3 series Processors
HP DL380 Gen9 Intel® Xeon® E5-2620v3 (2.4GHz/6-core/15MB/85W) FIO Processor Kit
719051-L21
HP DL380 Gen9 Intel® Xeon® E5-2623v3 (3GHz/4-core/10MB/105W) FIO Processor Kit
779556-L21
HP DL380 Gen9 Intel® Xeon® E5-2630v3 (2.4GHz/8-core/20MB/85W) FIO Processor Kit
719050-L21
HP DL380 Gen9 Intel® Xeon® E5-2630Lv3 (1.8GHz/8-core/20MB/55W) FIO Processor Kit
719060-L21
HP DL380 Gen9 Intel® Xeon® E5-2637v3 (3.5GHz/4-core/15MB/135W) FIO Processor Kit
NOTE: Ships with a High Performance Heatsink
719058-L21
HP DL380 Gen9 Intel® Xeon® E5-2640v3 (2.6GHz/8-core/20MB/90W) FIO Processor Kit
719049-L21
Performance Processors- E5-2600v3 series Processors
HP DL380 Gen9 Intel® Xeon® E5-2643v3 (3.4GHz/6-core/20MB/135W) FIO Processor Kit
NOTE: Ships with a High Performance Heatsink
719057-L21
HP DL380 Gen9 Intel® Xeon® E5-2650v3 (2.3GHz/10-core/25MB/105W) FIO Processor Kit
719048-L21
HP DL380 Gen9 Intel® Xeon® E5-2650Lv3 (1.8GHz/12-core/30MB/65W) FIO Processor Kit
719059-L21
HP DL380 Gen9 Intel® Xeon® E5-2660v3 (2.6GHz/10-core/25MB/105W) FIO Processor Kit
762764-L21
HP DL380 Gen9 Intel® Xeon® E5-2667v3 (3.2GHz/8-core/20MB/135W) FIO Processor Kit
NOTE: Ships with a High Performance Heatsink
719056-L21
HP DL380 Gen9 Intel® Xeon® E5-2670v3 (2.3GHz/12-core/30MB/120W) FIO Processor Kit
NOTE: Ships with a High Performance Heatsink
719046-L21
HP DL380 Gen9 Intel® Xeon® E5-2680v3 (2.5GHz/12-core/30MB/120W) FIO Processor Kit
762766-L21
