HP ProLiant DL380 Generation9 (Gen9)
c04375627 – DA – 15034 North America — Version 7 — February 17, 2015
NOTE: For more information regarding Intel Xeon processors, please see the following http://www.intel.com/xeon.
Intel® Xeon® processor E5-2600 v3 product family is designed to deliver the best combination of performance, built-in capabilities, and cost-
effectiveness. One (or two) of the following Intel® Xeon® E5-2600 v3 processors based on the model.
Up to two of the
following depending
on model
NOTE: All processors above 120W use a high efficiency Heatsink. Doublewide PCIe cards are only supported with this
Heatsink. For processors with a standard Heatsink that require double wide cards we would need to leverage the Graphics
Enablement kit (719082-B21).
Intel® C610 Series Chipset
Intel® E5-2600v3 Processor Family
NOTE: For more information regarding Intel chipsets, please see the following URL:
http://www.intel.com/products/server/chipsets/.
On System
Management Chipset
HP iLO (Firmware HP iLO4 2.0) 4GB NAND
NOTE: 1GB USB user space configurable via UEFI and accessible via iLO. Read and learn more in the iLO
QuickSpecs.
One of the following
depending on model
DDR4 Registered (RDIMM) or Load Reduced (LRDIMM)
(12 DIMM slots per processor, 4 channels per processor, 3 DIMMs per
channel)
Maximum Capacity (LRDIMM)
(24 x 64GB LRDIMM @2133MHz)
(24 x 16GB RDIMM @2133MHz)
NOTE: 64GB LRDIMMs, feature support to be available early 2015.
Advanced ECC uses single device data correction to detect and correct single and all
multibit error that occurs within a single DRAM chip.
