HP ProLiant DL380 Generation9 Overview

QuickSpecs
HP ProLiant DL380 Generation9 (Gen9)
Standard Features
c04375627 – DA – 15034 North America — Version 7 — February 17, 2015
Page 5
Online spare
Memory online spare mode detects a rank that is degrading and switches operation
to the spare rank.
Expansion Slots
Primary Riser
(Standard)
Expansion
Slots #
Technology
Bus Width
Connector
Width
Bus Number
Form Factor
Notes
1
PCIe 3.0
x8
x16
7
Full-height, half-length
slot
Proc 1
2
PCIe 3.0
x8
x16
10
Full-height, half-length
slot
Proc 1
3
PCIe 3.0
x8
x8
13
Half length, full height
slot
Proc 1
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment number.
** Indicates the number of physical electrical lanes running to the connector.
NOTE: All slots support PCIe cards to 150W or more depending on card, but an additional Power Cord Option is
required (PN 669777-B21). See Option Section below for offering.
Slot 2 PCIe Riser
(Optional 3-slot)
719073-B21
Expansion
Slots #
Technology
Bus Width
Connector
Width
Bus Number
Device
Number
Form Factor
Notes
4
PCIe 3.0
x16
x16
16
Full height,
full length slot
Proc 2
5
PCIe 3.0
x16
x16
20
Full height,
full length slot
Proc 2
6
PCIe 3.0
x8
x8
23
Full-height,
half-length
slot
Proc 2
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment number.
** Indicates the number of physical electrical lanes running to the connector.
NOTE: When populating the second optional riser slot, the second processor must be installed.
NOTE: All slots support PCIe cards to 150W or more depending on card but an additional Power Cord Option is
required (PN 669777-B21). See Option Section below for offering.
Slot 1 PCIe Riser
(Optional 2-slot)
719076-B21
Expansion
Slots #
Technology
Bus Width
Connector
Width
Bus Number
Device
Number
Form Factor
Notes
2
PCIe 3.0
x16
x16
0x05
Full height,
full length
slot
Proc 1
3
PCIe 3.0
x8
x8
0x08
Full-height,
half-length
slot
Proc 1
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment number.
** Indicates the number of physical electrical lanes running to the connector.
NOTE: This will replace the standard primary riser and supports double wide cards.
NOTE: All slots support PCIe cards to 150W or more depending on card, but an additional Power Cord Option is
required (PN 669777-B21). See Option Section below for offering.
Storage Controller
One of the following
depending on model
Entry Models
HP Dynamic Smart Array B140i Controller
NOTE: The embedded B140i controller will operate in UEFI only mode. For legacy support an additional controller
will be needed, and for CTO orders please also select the Legacy mode settings part, 758959-B22.
NOTE: The B140i defaults to AHCI off the chipset. Smart array needs to be enables on the SATA only models if
required.
NOTE: The B140i will not operate in Legacy mode.
Base Models
HP Dynamic Smart Array B140i Controller
HP Flexible Smart Array P440ar/2G FIO Controller
HP Flexible Smart Array P840/4G FIO Controller
Performance Models
HP Dynamic Smart Array B140i Controller
HP Flexible Smart Array P440ar/2GB

HP ProLiant DL380 Generation9 Specifications

General

Product Type	Server
Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v3/v4
Max Processors	2
Memory Slots	24 DIMM slots
Storage	Up to 12 LFF or 24 SFF drives
Drive Bays	12 LFF or 24 SFF
Storage Controller	HP Smart Array P440ar/2GB FBWC
RAID Support	0, 1, 5, 6, 10, 50, 60
Network	4 x 1GbE
Power Supply	1400W
Expansion Slots	Up to 6 PCIe 3.0
Remote Management	HP iLO
Operating System Support	Red Hat Enterprise Linux
Memory	Up to 3TB (24 x 128GB DDR4)
