HP ProLiant DL380 Generation9 (Gen9)
c04375627 – DA – 15034 North America — Version 7 — February 17, 2015
One of the following
depending on model
Ships standard in Performance Models
Optional: DVD-ROM, DVD-RW
8 SFF with optional Universal Media bay or 8SFF bay options
24 SFF plus optional 2 SFF drives rear
12 LFF plus optional 3 LFF drives rear
NOTE: The 3 LFF rear drives will consume space for the secondary riser.
NOTE: The 12LFF model also supports 2SFF rear which allows for the second riser.
NOTE: The Universal Media Bay (724865-B21) not available with the LFF model or the
24SFF model, and can only be populated in Bay1.
NOTE: The 8SFF can be upgraded with a drive cage to 16 or 24 SFF with field
upgrades. For optimal upgrade Bay2 should be populated second, with Bay 13 the
last to be populated for a field upgrade to 24 SFF.
NOTE: The 4LFF model cannot be upgraded to 12LFF in the field.
NOTE: All Pre-configured servers come with an embedded 10-Port SATA controller.
Optional HP Flexible Smart Array and Smart SAS HBA Controllers can be added.
24+2 x 1.2TB (with optional rear SFF drive cage)
24+2 x 1TB (with optional SFF drive cage)
12+3 x 6TB (with optional rear LFF drive cage)
12+3 x 6TB (with optional rear LFF drive cage)
24+2 x 1.6TB (with optional rear SFF drive cage)
12+3 x 1.6TB (with optional rear LFF drive cage)
HP 500W Flex Slot Platinum Hot Plug Power Supply
HP 800W Flex Slot Platinum Hot Plug Power Supply
HP 1400W Flex Slot Platinum Plus Hot Plug Power Supply
HP Flexible Slot (Flex Slot) Power Supplies share a common electrical and physical design that allows for hot plug,
tool-less installation into HP ProLiant Gen9 Performance Servers. Flex Slot power supplies are certified for high-
efficiency operation and offer multiple power output options, allowing users to "right-size" a power supply for
specific server configurations. This flexibility helps to reduce power waste, lower overall energy costs, and avoid
"trapped" power capacity in the data center.
All pre-configured servers ship with a standard 6-foot IEC C-13/C-14 jumper cord (A0K02A). This jumper cord is also
included with each standard AC power supply option kit. If a different power cord is required, please check the
ProLiant Power Cables web page.
To review the power requirements for your selected system, please use the HP Power Advisor Tool located at
http://www.hp.com/go/hppoweradvisor.
Power specifications and technical content for all HP Server power supplies can be found at
http://www.hp.com/go/proliant/powersupply.
One of the following
depending on model
NOTE: 1P models typically ship with 4 standard fans. The second processor option kit contains 2 additional
fans.
NOTE: The 12LFF and 24SFF models ship with 6 High Performance fans as standard.
NOTE: High Performance Fan Kit is available to meet ambient temperature environments.
NOTE: High Performance Fan Kit is required for Passive GPU support.
NOTE: The 8SFF Bay1 kit (719067-B21) will ship with 6 High efficiency fans.
2 (1 front, optional via Universal Media Bay, 724865-B21), 1 back not
active simultaneously
FlexibleLOM Network Ports
4 x 1Gb ports shipping standard with optional FlexibleLOM
