HP ProLiant DL380 Generation9 (Gen9)
Configuration Information - Factory Integrated Models
c04375627 – DA – 15034 North America — Version 7 — February 17, 2015
NOTE: Ships with a High Performance Heatsink
HP DL380 Gen9 Intel® Xeon® E5-2683v3 (2GHz/14-core/35MB/120W) FIO Processor Kit
NOTE: Ships with a High Performance Heatsink
HP DL380 Gen9 Intel® Xeon® E5-2690v3 (2.6GHz/12-core/30MB/135W) FIO Processor Kit
NOTE: Ships with a High Performance Heatsink
HP DL380 Gen9 Intel® Xeon® E5-2695v3 (2.3GHz/14-core/35MB/120W) FIO Processor Kit
NOTE: Ships with a High Performance Heatsink
HP DL380 Gen9 Intel® Xeon® E5-2697v3 (2.6GHz/14-core/35MB/145W) FIO Processor Kit
NOTE: Ships with a High Performance Heatsink
HP DL380 Gen9 Intel® Xeon® E5-2698v3 (2.3GHz/16-core/40MB/135W) FIO Processor Kit
NOTE: Ships with a High Performance Heatsink
HP DL380 Gen9 Intel® Xeon® E5-2699v3 (2.3GHz/18-core/45MB/145W) FIO Processor Kit
NOTE: Ships with a High Performance Heatsink
HP DL380 Gen9 Intel® Xeon® E5-2687Wv3 (3.1GHz/10-core/25MB/160W) FIO Processor Kit
NOTE: 2SFF rear drives are not supported with this processor in a 12LFF Model.
NOTE: If two processors are desired, select one xxxxxx-L21 and one xxxxxx-B21.
NOTE: Up to 2 processors supported. Mixing different processor models is not supported.
NOTE: DDR4 speed is the maximum memory speed of the processor. Actual memory speed may depend on the
quantity and type of DIMMs installed.
NOTE: For the Intel® C600 Chipset E5-2600 Series, the letter preceding the model number indicates the Product Line
(E3, E5, E7); 2600x v#, 2 = number of CPUs in a Node, 6 is socket/segment designation, 00 = Processor SKU, x = L for
low power SKUs and v# (not yet designated) = version number.
NOTE: Select one or more memory from section below.
NOTE: LRDIMM, RDIMM are all distinct memory technologies and cannot be mixed within a server. The majority of
ProLiant Gen9 servers support LRDIMM and RDIMM.
NOTE: HP memory from previous generation servers are not qualified or warranted with this HP ProLiant server. HP
SmartMemory is required to realize the memory performance improvements and enhanced functionality listed in this
document for Gen9.
NOTE: If only one processor is installed, only half of the total DIMM slots are available. When populating with two
processors all DIMM slots are available.
NOTE: Kits described as LP include Low Power DIMMs. For more information on ProLiant Energy Efficient Features,
see: http://www.hp.com/go/proliant-energy-efficient .
NOTE: Depending on the memory configuration and processor model, the memory speed may run at 2133MHz,
1866MHz, 1600MHz or 1333MHz. Please see Memory Population Table or Online Memory Configuration Tool at:
http://www.hp.com/go/ddr4memory-configurator .
Registered DIMMs (RDIMMs) for E5-2600v3 Series
HP 4GB (1x4GB) Single Rank x8 DDR4-2133 CAS-15-15-15 Registered Memory Kit
HP 8GB (1x8GB) Single Rank x4 DDR4-2133 CAS-15-15-15 Registered Memory Kit
HP 8GB (1x8GB) Dual Rank x8 DDR4-2133 CAS-15-15-15 Registered Memory Kit
HP 16GB (1x16GB) Dual Rank x4 DDR4-2133 CAS-15-15-15 Registered Memory Kit
Load Reduced DIMMs (LRDIMMs) for E5-2600v3 Series
HP 32GB (1x32GB) Quad Rank x4 DDR4-2133 CAS-15-15-15 Load Reduced Memory Kit
HP 16GB (1x16GB) Dual Rank x4 DDR4-2133 CAS-15-15-15 Load Reduced Memory Kit
NOTE: Mixing of power supplies in the same server is not supported. All power supplies must be of the same input
voltage, output rating, and efficiency rating. If non-matching power supplies are installed, you may receive an error
message and/or experience operational issues with your server
NOTE: Prior to selecting a power supply option, it is highly recommended that you review your server configuration in
the HP Power Advisor tool to determine the right size power supply for your server configuration. The HP Power
Advisor is located at: www.hp.com/go/hppoweradvisor.
HP Flex Slot Platinum Hot-Plug Power Supplies
HP 500W Flex Slot Platinum Hot Plug Power Supply Kit
HP 800W Flex Slot Platinum Hot Plug Power Supply Kit
HP 1400W Flex Slot Platinum Plus Hot Plug Power Supply Kit
NOTE: The above power supply options are all 80Plus Platinum-certified with an efficiency rating
of up to 94%. Support for HP Power Discovery Services is included with the 1400W Flex Slot option.
