HP ProLiant DL380 Generation9

QuickSpecs
HP ProLiant DL380 Generation9 (Gen9)
Core Options
c04375627 – DA – 15034 North America — Version 7 — February 17, 2015
Page 28
NOTE: Only one FlexibleLOM can be added to the server. These options are upgradeable
and can be changed from the original configuration after the server is shipped.
NOTE: Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables
for fiber-optic environments must be purchased separately. Please see the related NIC
QuickSpecs for Technical Specifications and additional information:
http://www.hp.com/go/ProLiantNICs.
HP InfiniBand
HP InfiniBand FDR 2-port 545QSFP Adapter
NOTE: The RHEL6.5 driver is not part of SPP, but may be downloaded here:
http://downloads.linux.hp.com/SDR/downloads/MLNX_OFED/.
702211-B21
HP InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+QSFP Adapter
764284-B21
HP InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+FLR-QSFP Adapter
764285-B21
HP InfiniBand QDR/Ethernet 10Gb 2-port 544+FLR-QSFP Adapter
764286-B21
QLogic InfiniBand 4X QDR PCI-E G2 Dual Port HCA
583211-B21
HP I/O Expansion
Options
HP DL380 Gen9 Primary 2 Slot GPU Ready Riser Kit
NOTE: This is for slot 1 and supports double wide GPGPUs.
Slot1: 1x Gen3 x16 FH/FL, 1xGen3 x8 FH/HL.
719076-B21
HP DL380 Gen9 Secondary 3 Slot GPU Ready Riser Kit
NOTE: This is for slot 2 and supports double wide GPGPUs.
Slot2: 2x Gen3 x16 FH/FL, 1xGen3 x8 FH/HL.
NOTE: To support Graphics cards please also order the DL380 Gen9 Graphics Enablement
kit, 719082-B21.
719073-B21
HP Power Supplies
HP Flex Slot Platinum Hot-plug Power supplies
HP 500W Flex Slot Platinum Hot Plug Power Supply Kit
720478-B21
HP 800W Flex Slot Platinum Hot Plug Power Supply Kit
720479-B21
HP 1400W Flex Slot Platinum Plus Hot Plug Power Supply Kit
720620-B21
NOTE: All power supplies must be of the same input voltage, output rating, and efficiency
rating. If non-matching power supplies are installed, you may receive an error message
and/or experience operational issues with your server.
NOTE: Prior to selecting a power supply option, it is highly recommended that you review
your server configuration in the HP Power Advisor tool to determine the right size power
supply for your server configuration. The HP Power Advisor is located at:
http://www.hp.com/go/hppoweradvisor.
NOTE: The above power supply options are all 80Plus Platinum-certified with an efficiency
rating of up to 94%. Support for HP Power Discovery Services is included with the 1400W
Flex Slot option. Power specifications and technical content for all HP Server power
supplies can be found at http://www.hp.com/go/proliant/powersupply.
NOTE: Maximum of 2 Flex Slot PS per platform.
HP Computation and
Graphics Accelerators
HP DL380 Gen9 Graphics Enablement Kit
NOTE: This GPU enablement kit includes 2 Heatsinks and6 cables to enable double wide
GPUs to be supported.
NOTE: For doublewide GPU support you are required to have at least 1x1400W Power Supply
(720620-B21), per card.
NOTE: There are limitations on the server model and processor supported when
adding Graphics accelerators.
NOTE: Passive cards will require the addition of the High Performance Fan Kit (719079-B21).
719082-B21
HP NVIDIA GRID K1 Quad GPU PCIe Graphics Accelerator
NOTE: For doublewide GPU support you are required to have at least 1x1400W Power
Supply (720620-B21), per card.
NOTE: This card only runs at PCIeGen2 speeds.
NOTE: The Primary GPU riser (719076-B21) is required to support this in slot1.
NOTE: The secondary GPU riser (719073-B21) is required to support this in slot2 (2nd
processor required).
NOTE: There are limitations on the server model and processor supported when
adding Graphics accelerators.
J0G94A
