QuickSpecs
HPE ProLiant DL380 Generation9 (Gen9)
Standard Features
Page 7
One of the following
depending on
m
odel
Hard Drives
None ship standard
Hard Drive Bays
8 SFF with optional Universal Media Bay, 8 SFF bay or 6 NVME drive options
24 SFF plus optional 2 SFF drives rear
12 LFF plus optional 3 LFF drives rear
NOTE: The 3 LFF rear drives will consume space for the secondary riser.
NOTE: The 12 LFF model also supports 2 SFF rear which allows for the
second riser.
NOTE: The 6 NVMe drive option can only be leveraged in the SFF model
and replaces Bay 2.
4 LFF drive bays total
NOTE: The Universal Media Bay (724865-B21) not available with the LFF
model or the 24SFF model, and can only be populated in Bay1.
NOTE: The 8SFF can be upgraded with a drive cage to 16 or 24 SFF with
field upgrades. For optimal upgrade Bay2 should be populated second,
with Bay 13 the last to be populated for a field upgrade to 24 SFF.
NOTE: The 4LFF model cannot be upgraded to 12LFF in the field.
NOTE: All Pre-configured models come with an embedded 10-Port SATA
controller. Optional HPE Flexible Smart Array and Smart SAS HBA
Controllers can be added.
Maximum Internal
Storage
CAPACITY
CONFIGURATION
Hot Plug SFF SAS
52.0TB
24+2 x 2TB (with optional rear SFF drive cage)
Hot Plug SFF SATA
52.0TB
24+2 x 2TB (with optional SFF drive cage)
Hot Plug LFF SAS
120.0TB
12+3 x 8TB (with optional rear LFF drive cage)
Hot Plug LFF SATA
150.0TB
12+3 x 10TB (with optional rear LFF drive cage)
Hot Plug SFF SAS SSD
99.84TB
24+2 x 3.84TB (with optional rear SFF drive cage)
Hot Plug LFF SATA SSD
57.6B
12+3 x 3.84TB (with optional rear LFF drive cage)
Hot Plug SFF NVMe PCIe
SSD
12TB NVMe + 36TB
SFF
6x2TB NVMe plus 36TB with 18 SFF (Bay 1, bay 3
and optional rear drive support)
Power Supply
HPE 500W Flex Slot Platinum Hot Plug Power Supply
NOTE:
Available in 94% efficiency.
HPE 800W Flex Slot Platinum Hot Plug Power Supply
NOTE:
Available in 94% and 96% efficiency.
NOTE:
Also available in -48VDC and 227VAC/380VDC power inputs.
HPE 1400W Flex Slot Platinum Plus Hot Plug Power Supply
NOTE:
Available in 94% efficiency.
HPE Flexible Slot Battery Backup Unit Kits
NOTE:
Flex Slot Battery Backup provides 750W output and 500W in paralleled configuration.
HPE Flexible Slot (Flex Slot) Power Supplies share a common electrical and physical design that allows
for hot plug, tool-less installation into HPE ProLiant Gen9 Performance Servers. Flex Slot power supplies
are certified for high-efficiency operation and offer multiple power output options, allowing users to
"right-
size" a power supply for specific server configurations. This flexibility helps to reduce power waste,
lower overall energy costs, and avoid "trapped" power capacity in the data center.
All pre-configured servers ship with a standard 6-foot IEC C-13/C-14 jumper cord (A0K02A). This
jumper cord is also included with each standard AC power supply option kit. If a different power cord is
required, please check the ProLiant Power Cables web page.
To review the power requirements for your selected system, please use the HPE Power Advisor Tool
located at http://www.hp.com/go/hppoweradvisor.

HP ProLiant DL380 Generation9 Specifications

General

Product Type	Server
Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v3/v4
Max Processors	2
Memory Slots	24 DIMM slots
Storage	Up to 12 LFF or 24 SFF drives
Drive Bays	12 LFF or 24 SFF
Storage Controller	HP Smart Array P440ar/2GB FBWC
RAID Support	0, 1, 5, 6, 10, 50, 60
Network	4 x 1GbE
Power Supply	1400W
Expansion Slots	Up to 6 PCIe 3.0
Remote Management	HP iLO
Operating System Support	Red Hat Enterprise Linux
Memory	Up to 3TB (24 x 128GB DDR4)
