HP ProLiant DL380p Gen8 - Remove the PCI Riser Cage

Operations 29
7.
Release the full-length expansion board retainer, and then remove the PCIe riser cage.
8. Remove the full-length expansion board.
To replace the component, reverse the removal procedure.
Remove the PCI riser cage
CAUTION: To prevent damage to the server or expansion boards, power down the server and
remove all AC power cords before removing or installing the PCI riser cage.
1. Power down the server (on page 23).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Extend the server from the rack (on page 23).
4. Remove the access panel (on page 24).
