Hardware options installation 24

Secure the cable with the cable clamp.

7. Install the access panel.

8. Power up the server (on page 6).

Cabling an HP 8 Internal Port SAS/SATA Host Bus Adapter with RAID card

(ML110 G4)

IMPORTANT: The LED cable must be connected to the HP 8 Internal Port SAS/SATA Host Bus

Adapter card before the card is installed in the server. If the card is already installed, remove

it before connecting the cable. For more information, see the HP ProLiant ML110 Generation

4 Server Maintenance and Service Guide.

1. Power down the server (on page 6).

2. Remove the access panel ("Access panel" on page 6).

3. Connect the LED cable to the card.

4. Install the card.

For more information, see the documentation that ships with the option and see "Expansion board

options (on page 41)."

5. Connect the LED cable to the system board.
