HP ProLiant ML110 - G2 Server User Manual

Hardware options installation 26
Installing the LED cable (ML150 G3)
Connector location (ML150 G3)
Cabling an HP Smart Array E200 controller card (ML150 G3)
1. Power down the server (on page 6).
2. Remove the access panel ("Access panel" on page 6).
3. Install the card.
For more information, see the documentation that ships with the option and see "Expansion board
options (on page 41)."
4. Connect the LED cable to the card and to the system board.
5. Unfasten the cable tie.

HP ProLiant ML110 - G2 Server Specifications

General

Server Type	Tower
Chipset	Intel E7210
Memory Type	DDR SDRAM
Maximum Memory	4 GB
Optical Drive	Optional
Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Pentium 4
Storage Controller	Integrated SATA
Drive Bays	2 x 3.5" internal
Network Controller	Integrated Broadcom Gigabit Ethernet
Power Supply	300W
Operating System Support	Microsoft Windows Server 2003, Red Hat Linux
