HP ProLiant ML150 Quickspecs

NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, HP recommends the use of
an HP approved configurator. Contact your local sales representative for additional information.
HP Insight Software HP Insight Control
HP Insight Management Media Kit 436222-B21
NOTE: HP Insight Management Media Kit contains DVDs without licenses. Contains HP
Systems Insight Manager, HP Insight Control, HP Matrix Operating Environment, and
Virtual Connect Enterprise Manager software. Uses an integrated installer to perform
quick and accurate software installation and updates.
HP Entry-Level Server
Management
HP Lights-Out 100i (LO100i) Advanced including 1yr 24x7 Support Single Server License 530521-B21
NOTE: Other license types available, please check LO100i Advanced QuickSpecs at:
http://www.hp.com/go/lo100 for more details.
HP Port Options HP Non-Hot Plug Internal SAS/SATA 4 Port Cable Kit
NOTE: This cable is required when adding Smart Array P410 Controller on Non-Hot Plug
SATA/SAS server models.
487734-B21
HP Security HP Trusted Platform Module Option
NOTE: The TPM (Trusted Platform Module) is a microcontroller chip that can securely
store artifacts used to authenticate the server platform. These artifacts can include
passwords, certificates and encryption keys. Windows® BitLocker™ Drive Encryption
(BitLocker) is a data protection feature available in Windows Server® 2008. BitLocker
leverages the enhanced security capabilities of a Trusted Platform Module (TPM)
version 1.2. The TPM works with BitLocker to help protect user data and to ensure that
a server running Windows Server 2008 has not been tampered with while the system
was offline.
NOTE: For more information about TPM, including a white paper, go to:
www.hp.com/go/TPM
NOTE: ProLiant OS pre-installed units will come with the partition required for TPM
deployment.
NOTE: The TPM key is unique to every TPM deployed server and must be retained.
Misplacing or losing the key could result in data loss.
488069-B21
HP Storage Controllers SAS Controller
Smart Array P212 Controller
HP Smart Array P212/ZM 1-ports Int/1-ports Ext PCIe x8 SAS Controller 462828-B21
HP Smart Array P212/256 1-ports Int/1-ports Ext PCIe x8 SAS Controller 462834-B21
Smart Array P410 Controller
HP Smart Array P410/256 2-ports Int PCIe x8 SAS Controller 462862-B21
HP Smart Array P410/512 BBWC 2-ports Int PCIe x8 SAS Controller 462864-B21
HP Smart Array P410/512 FBWC 2-ports Int PCIe x8 SAS Controller 578230-B21
HP Smart Array P410/1G FBWC 2-ports Int PCIe x8 SAS Controller 572532-B21
QuickSpecs
HP ProLiant ML150 Generation 6 (G6)
Additional Options
DA - 13249 North America — Version 33 — September 24, 2012 Page 23

HP ProLiant ML150 Specifications

General

Tcase	72.8 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Scalability	2S
Processor cache	15 MB
Processor cores	6
Processor model	E5-2603V3
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor codename	Haswell
Motherboard chipset	Intel C610
Number of QPI links	2
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600 MHz
Memory bandwidth supported by processor (max)	51 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID support	-
HDD interface	Serial ATA
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Memory slots	16x DIMM
Internal memory	4 GB
Memory clock speed	2133 MHz
Maximum internal memory	256 GB
Memory layout (slots x size)	1 x 4 GB
Graphics card family	NVIDIA
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Chassis type	Rack (1U)
Power supply	550 W
Processor ARK ID	83349
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
PCI Express slots version	3.0

Weight and Dimensions

Depth	620 mm
Width	200 mm
Height	432.6 mm
Weight	22230 g
