HP ProLiant ML150

HP Half-Height SATA DVD-
ROM Optical Drive
Disk Applicable Disk CD-ROM, CD-XA, CD-DA
(Mode 1, Mode 2, Form 1 and 2)
Photo CD (Single and Multi-session)
Mixed Mode (Audio and Data combined)
CD-R, CD-RW, DVD-ROM, DVD+R, DVD+RW
Capacity 4.7 GB (DVD-5)
8.54 GB (DVD-9)
Block Size DVD Media 2,048 bytes
Interface SATA 1.56Gb/s
Access Times (typical) Random <140 ms
Full-Stroke <250 ms
Data Transfer Rate Sustained 8100 to 21600 KB/s (6X to 16X)
Cache Buffer 128 KB
Start-up Time (typical) < 7 seconds
Stop Time < 4 seconds
Laser Parameters Type Semiconductor Laser GaA1As
Wave Length 780 ± 25 nm
Operating Conditions Temperature 41° to 113° F (5° to 45° C)
Humidity 10% to 90%
Dimensions (HxWxD, maximum) 1.7 x 5.85 x 8.11 in (4.49 x 15.0 x 20.3 cm)
Weight 2.64 lb (1.2 kg)
Smart Array P410
Controller
Dimensions (not including
bracket)
Low Profile PCIe Form Factor
19.05 cm x 24.13 cm x 5.72cm (7.5 in x 9.5 in x 2.25 in)
Disk Drive and Enclosure
Interface
3G SAS (Serial Attached SCSI)
1.5G SATA (Serial ATA)
SAS Connectors x8 3G SAS provides 2.4GB/s maximum bandwidth
Cache Memory Speed DDR2-533MHz with 40 or 72-bit wide bus provides up to 4.2 GB/s maximum
bandwidth.
Server Interface x8 2.5G PCIe 2.0 provides 2GB/s maximum bandwidth
SAS Speed x8 3G SAS provides 2.4GB/s maximum bandwidth
Logical Drives Supported Up to 32 logical drives
Host Memory Addressing 64-bit, supporting greater than 4GB server memory space
RAID Support RAID 6, 6+0 (Advanced Data Guarding)
NOTE: The minimum of 256 MB cache, battery kit, and Smart Array Advanced
Pack License Key upgrade is required to enable RAID 6, 6+0
RAID 5, 5+0 (Distributed Data Guarding)
NOTE: The 256MB upgrade is required to enable RAID 5 support on the Smart
Array P410i. RAID 5+0 is available with the addition of the optional Battery kit
upgrade
RAID 1+0 (Striping & Mirroring)
RAID 0 (Striping)
QuickSpecs
HP ProLiant ML150 Generation 6 (G6)
Technical Specifications
DA - 13249 North America — Version 33 — September 24, 2012 Page 43
