HP ProLiant ML150 Quickspecs

Server Power Cord One Lowline NEMA power cord
Power Supply Standard: HP 460W Factory Integrated Power Supply
Optional: HP 750W Common Slot Gold Hot Plug Power Supply
NOTE: The installation of the optional 750W Redundant Power Supply requires a HP Redundant Power
Supply Enablement Kit (P/N 508544-B21).
NOTE: Two (2) 750W Redundant Power Supply units and one (1) RPS enablement kit (P/N 508544-B21) are
required to achieve redundancy.
NOTE: The 2nd hot plug hard disk drive cage requires the purchase of 750W Redundant Power Supply,
Redundant Power Supply Enablement Kit and HP Smart Array P410 Controller (if not already part of the
configuration)
System Fans System supports a total of four (4) fans
Two (2) fans ship standard for 1P configuration - Non-hot plug, Non-redundant system fans
NOTE: For redundancy, please order a redundant fan option kit (513927-B21) which comes with 2 fans
Three(3) fans ship standard for 2P configuration - Non-hot plug, Non-redundant system fans
NOTE: If customer orders the standalone redundant fan option kit (513927-B21), two (2) fans in a two-fan
packaged box will be received. Only one (1) fan is required for system redundancy. The other one can be
saved as a spare part.
NOTE: If customer orders the redundant fan kit along with the server, the extra fan will not be received.
Operating Systems and
Virtualization Software
Support for ProLiant
Servers
Microsoft Windows Server Hyper V
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
NOTE: For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization
Software and latest listing of software drivers available for your server, please visit our Support Matrix at:
http://www.hp.com/go/ossupport
Graphics 32MB shared supporting all display resolutions up to 1600x1200 16bpp @75Hz
NOTE: 8MB is dedicated to video memory.
Form Factor Tower (5U)
NOTE: Rack mounting available via HP Tower to Rack Conversion Tray, Universal Kit. Please see the
options section in this QuickSpecs.
QuickSpecs
HP ProLiant ML150 Generation 6 (G6)
Standard Features
DA - 13249 North America — Version 33 — September 24, 2012 Page 5

HP ProLiant ML150 Specifications

General

Tcase	72.8 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Scalability	2S
Processor cache	15 MB
Processor cores	6
Processor model	E5-2603V3
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor codename	Haswell
Motherboard chipset	Intel C610
Number of QPI links	2
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600 MHz
Memory bandwidth supported by processor (max)	51 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID support	-
HDD interface	Serial ATA
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Memory slots	16x DIMM
Internal memory	4 GB
Memory clock speed	2133 MHz
Maximum internal memory	256 GB
Memory layout (slots x size)	1 x 4 GB
Graphics card family	NVIDIA
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Chassis type	Rack (1U)
Power supply	550 W
Processor ARK ID	83349
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
PCI Express slots version	3.0

Weight and Dimensions

Depth	620 mm
Width	200 mm
Height	432.6 mm
Weight	22230 g
