14. Lift the chassis up, and then route the display cable (3) and the backlight cable (4) through the holes in
the chassis.
15. Remove the chassis from the display panel.
16. Remove the seven screws that secure the plastic frame from the display, and then lift the frame o the
display.
IMPORTANT: Install the new display panel together with all other parts in the replacement kit. Do not
reuse any old parts. Return all old parts to HP for warranty processing.
CAUTION: It is very important to use the exact cable that shipped with the replacement panel. Failure
to use the correct cable may result in panel failure.
To replace the rear enclosure and main chassis, reverse the removal procedures.
50 Chapter 4 Removal and Replacement Procedures
