Using the Touch Screen
The touch screen shows all important information regarding camera settings as well as the visual image of your
image or video. It also provides all kinds of touch buttons to control the settings for the camera. The display on the
touch screen is called the On Screen Display or OSD.
Touch screen Layout
Photo Mode Screen Layout
No. Item Description
1 AF lamp
Indicates AF lamp is enabled. Please see page 42 for additional
details.
2 Display focus area settings Use to frame subject to capture.
3 Zoom indicator
Displays zoom type and level. Please see page 22 for additional
details.
4 Shots remaining Indicates the remaining shots available.
5 Battery Indicates approximate battery level.
6 Storage media
Indicates current storage media in use. Options are Internal
memory and SD/SDHC memory card.
7 Shake warning
Indicates that the camera is moving too much that may result in
image blur. Use of a tripod or steady hand may be required.
8
Touch button –
AF area/Face tracking
Tap to display the AF area/face tracking popup menu.
9 Touch button - Display Tap to switch the display mode of the LCD monitor.
10 Image Stabilizer
Indicates if the image stabilizer function is enabled. Please see
page 22 for additional details.
11 Resolution
Displays photo resolution settings. Please see page 39 for
additional details.
12 Quality Displays quality settings. Please see page 39 for additional details.
13 Sharpness
Displays sharpness settings. Please see page 43 for additional
details.
14 Metering
Displays metering settings. Please see page 41 for additional
details.
15 White balance
Displays white balance settings. Please see page 40 for additional
details.
To Next Page
