HP R1500 G2 User Manual

Part Number
Part NumberPart Number
Part Number Operating Voltage
Operating VoltageOperating Voltage
Operating Voltage
Settings
SettingsSettings
Settings
Power Out (VA/Watts)
Power Out (VA/Watts)Power Out (VA/Watts)
Power Out (VA/Watts) Input Connection
Input ConnectionInput Connection
Input Connection Output Connection
Output ConnectionOutput Connection
Output Connection
Low-Voltage Models
Low-Voltage ModelsLow-Voltage Models
Low-Voltage Models
AF419A 120V 1440/1000 NEMA 5-15P (4) Nema 5-15R
NOTE:
NOTE:NOTE:
NOTE: Part Number AF419A is user selectable for 110V, 120V, or 127V via the rear panel dip switch
AF421A 100V 1200/900 NEMA 5-15P (4) Nema 5-15R
110v 1320/1000 Nema 5-15P (4) Nema 5-15R
NOTE:
NOTE: NOTE:
NOTE: Part Number AF421A is user selectable for 100V, or 110V via rear panel dip switch
High Voltage Model
High Voltage ModelHigh Voltage Model
High Voltage Model
AF418A 230V 1500/1000 IEC-320 C14 (4) IEC 320-C13
NOTE:
NOTE: NOTE:
NOTE: Part Number AF418A is user selectable for 220V, 230V, or 240V via the rear panel dip switch
Kit Contents
Kit ContentsKit Contents
Kit Contents HP UPS R1500 G2
HP Power Management Software CD
Power Products Documentation CD
Depth adjustable fixed rack mounting rails
Serial communications cable (1.83 meters)
Additional IEC to IEC jumper cords, and detachable country specific input cord with the high
voltage INTL model
USB communications cable (1.8 meters)
QuickSpecs
HP R1500 G2 UPS
HP R1500 G2 UPSHP R1500 G2 UPS
HP R1500 G2 UPS
UPS Model Matrix
DA - 12507 North America — Version 10 — June 20, 2011 Page 7

HP R1500 G2 Specifications

General

Interface Port	USB
Input Frequency	50/60 Hz
Output Frequency	50/60 Hz
Output Power Capacity	1500 VA
Battery Type	Sealed Lead-Acid
Transfer Time	4 ms
