HP R1500 User Manual

Installation 10
Installation
In this section
Precautions............................................................................................................................................ 10
Preparing to install the hardware ............................................................................................................. 10
Installing the mounting rails ..................................................................................................................... 11
Installing the UPS ................................................................................................................................... 14
Connecting the batteries.......................................................................................................................... 15
Attaching the UPS front bezel .................................................................................................................. 16
Selecting the UPS voltage configuration .................................................................................................... 17
Connecting the host computer.................................................................................................................. 17
Connecting the Network Transient Protectors............................................................................................. 18
Connecting the UPS to utility power.......................................................................................................... 19
Connecting devices to the UPS................................................................................................................. 19
Powering up the UPS .............................................................................................................................. 20
Charging the UPS batteries...................................................................................................................... 20
Precautions
Save these instructions. This document contains important safety instructions that should be followed
during installation, operation, and maintenance of the UPS and batteries.
WARNING: A risk of personal injury from electric shock and hazardous energy levels
exists. The installation of options and routine maintenance and service of this product
must be performed by individuals who are knowledgeable about the procedures,
precautions, and hazards associated with AC power products.
WARNING: To prevent personal injury from earth conductor leakage current:
• Do not operate the UPS while disconnected from the utility power source.
• Disconnect load devices before disconnecting the UPS from the utility power source.
WARNING: To prevent personal injury, prepare the area and observe all materials
handling procedures when transporting the UPS. When fully assembled, the UPS weighs
23 kg (50.5 lb).
Preparing to install the hardware
Before installing the hardware:
1. Be sure the necessary tools and materials ("Tools required" on page 11) are available.
2. Select an installation site ("Selecting a site" on page 11).
3. Prepare the equipment ("Readying the equipment" on page 11) for installation in the rack.

HP R1500 Specifications

General

Nominal Output Voltage	120V
Nominal Input Voltage	120V
Input Connections	NEMA 5-15P
Output Frequency	50/60 Hz +/- 3 Hz
Input Frequency	50/60 Hz +/- 3 Hz (auto sensing)
Form Factor	Tower
Input Voltage	120V
Output Voltage	120V
Frequency	50/60 Hz
Typical Recharge Time	3 hours
Transfer Time	4 ms typical
Output Waveform	Stepped approximation to a sinewave
Communication Ports	USB, Serial
Battery Type	Sealed Lead Acid
Data Line Protection	RJ-45
Capacity	1500 VA
Device Type	Line Interactive UPS
