17
Specify the System Requirements
System Electrical Specifications
Table 3
Description Specification
AC Input Voltage Range
a
200 to 240 VAC
AC Input Line frequency 50 to 60 Hz
AC Input Current 18 A (max load at 200 VAC)12 A (max load at 240
VAC)
AC Inrush Current TBD
AC Input Power 1250 VA maximum
Power Supply Output
Rating
1163 watts DC continuous
Holdup without system
reset
25ms at 50/60Hz (1 cycle, or 500ms)
Battery Backup Time 15 minutes
With optional external PowerTrust UPS. Without
the optional UPS there is no battery backup.
a. The power supply auto-ranges to the AC voltage and frequency. It does
not have to be reconfigured to operate over its rated operating ranges.
