HP Smart Array P800 User Manual

Installing the controller hardware 11
c.
Release the tab.
3. Connect the other end of the cable to the SAS input connector of the external storage enclosure.
• If the enclosure uses a standard SAS 4x connector, insert the cable connector into the enclosure
connector, and then tighten the lock screws on the cable connector.
• If the enclosure uses a mini SAS 4x connector, pull back the tab on the cable connector, insert
the cable connector into the enclosure connector, and then release the tab.
4. Power up the enclosure.
5. Power up the server.
SAS cable part numbers
To order additional cables, use the option kit part number.
Approximate cable
length
Type of cable
Option kit part
number
Cable assembly
number
1 m (3 ft) Mini SAS 4x to standard SAS 4x 419570-B21 408908-002
2 m (6 ft) Mini SAS 4x to mini SAS 4x 407339-B21 407344-003
Mini SAS 4x to standard SAS 4x 419571-B21 408908-003
4 m (13 ft) Mini SAS 4x to mini SAS 4x 432238-B21 407344-004
Mini SAS 4x to standard SAS 4x 419572-B21 408908-004
6 m (20 ft) Mini SAS 4x to mini SAS 4x 432239-B21 407344-005
Mini SAS 4x to standard SAS 4x 419537-B21 408908-005
