used to perform system recovery if the hard drive becomes corrupted. System recovery reinstalls the

original operating system and software programs that were installed at the factory and then congures the

settings for the programs. HP Recovery media can also be used to customize the system or restore the

factory image if you replace the hard drive.

–

Only one set of recovery media can be created. Handle these recovery tools carefully, and keep them

in a safe place.

–

HP Recovery Manager examines the computer and determines the required storage capacity for the

media that will be required.

–

To create recovery discs, your computer must have an optical drive with DVD writer capability, and

you must use only high-quality blank DVD-R, DVD+R, DVD-R DL, or DVD+R DL discs. Do not use

rewritable discs such as CD±RW, DVD±RW, double-layer DVD±RW, or BD-RE (rewritable Blu-ray) discs;

they are not compatible with HP Recovery Manager software. Or, instead, you can use a high-quality

blank USB

ash drive.

–

If your computer does not include an integrated optical drive with DVD writer capability, but you

would like to create DVD recovery media, you can use an external optical drive (purchased separately)

to create recovery discs. If you use an external optical drive, it must be connected directly to a USB

port on the computer; the drive cannot be connected to a USB port on an external device, such as a

USB hub. If you cannot create DVD media yourself, you can obtain recovery discs for your computer

from HP. You can nd contact information on the HP website. Go to http://www.hp.com/support,

select your country or region, and follow the on-screen instructions.

–

Be sure that the computer is connected to AC power before you begin creating the recovery media.

–

The creation process can take an hour or more. Do not interrupt the creation process.

–

If necessary, you can exit the program before you have nished creating all of the recovery DVDs. HP

Recovery Manager will nish burning the current DVD. The next time you start HP Recovery Manager,

you will be prompted to continue.

To create HP Recovery media using HP recovery manager:

IMPORTANT: For a tablet with a detachable keyboard, connect the tablet to the keyboard base before

beginning these steps.

1. Type recovery in the taskbar search box, and then select HP Recovery Manager.

2. Select Create recovery media, and then follow the on-screen instructions.

If you ever need to recover the system, see Recovering using HP Recovery Manager on page 60.

Using Windows tools

You can create recovery media, system restore points, and backups of personal information using Windows

tools.

NOTE: If storage is 32 GB or less, Microsoft System Restore is disabled by default.

For more information and steps, see the Get Help app.

▲ Select the Start button, and then select the Get Help app.

NOTE: You must be connected to the Internet to access the Get Help app.

Creating recovery media and backups 59

Questions and Answers:

Need help?

Do you have a question about the HP Spectre 13 and is the answer not in the manual?

HP Spectre 13 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Silver
Housing material	Aluminium, Carbon fibre
Country of origin	China
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	1866 MHz
Memory form factor	On-board
Internal memory type	LPDDR3-SDRAM
Memory layout (slots x size)	1 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
SSD form factor	M.2
Card reader integrated	No
Total storage capacity	1024 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
LED backlight	Yes
Display surface	Gloss
Display diagonal	13.3 \
Native aspect ratio	16:9
On-board graphics card ID	0x5916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 620
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Speakers manufacturer	Bang & Olufsen
Number of built-in speakers	2
WWAN	Not installed
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB Sleep-and-Charge ports	3
Cable lock slot type	Kensington
AC adapter power	45 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19 V
Battery capacity	38 Wh
Battery life (max)	8 h
Number of battery cells	4
Pointing device	Touchpad
Bus type	OPI
Stepping	H0
Tjunction	100 °C
Processor cache	4 MB
Processor model	i7-7500U
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor socket	BGA 1356
Processor codename	Kaby Lake
Configurable TDP-up	25 W
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.9 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR
Processor code	SR2ZV
Processor ARK ID	95451
Processor package size	42 x 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
