Tablet major components
Item Component Spare part number
(1) Display panel assembly:
NOTE: The display panel assembly does not include the display panel assembly cable. The display panel assembly cable
is included in the Cable Kit, spare part number 742103-001. See
Cable Kit on page 21 for more Cable Kit spare part
information.
13.3-inch, AG, FHD, WLED TouchScreen, display assembly 737696-001
13.3-inch, AG, HD, WLED TouchScreen, display assembly 737697-001
(2) Heat sink (includes 3 captive screws and replacement thermal material) 737216-001
(3) RTC battery (includes cable and double-sided adhesive) 740187-001
(4) Webcamera/microphone module (includes double-sided adhesive and grounding tape) 736900-001
16 Chapter 3 Illustrated parts catalog
