4. Remove the hinge assembly (5) and cables.
Reverse this procedure to install the hinge assembly.
Keyboard
NOTE: The keyboard spare part kit includes the keyboard bracket and keyboard cable.
Description Spare part number
For use in Belgium 742110-A41
For use in Denmark, Finland, and Norway 742110-DH1
For use in France 742110-051
For use in Germany 742110-041
For use in Italy 742110-061
For use in the Netherlands 742110-B31
For use in Portugal 742110-131
For use in Russia 742110-251
For use in Saudi Arabia 742110-171
For use in Switzerland 742110-BG1
For use in the United Kingdom and Singapore 742110-031
Top cover for use in Belgium, Denmark, Finland, France, Germany, Italy, Norway, Portugal, Switzerland,
Singapore, and the United Kingdom
742388-001
Top cover for use in the Netherlands, Russia, and Saudi Arabia 742387-001
Before removing the keyboard, follow these steps:
Keyboard 75
