micro Solid-state drive (mSSD)
Description Spare part number
256-GB mSATA-3 mSSD 749037-001
128-GB mSSD 737218-001
Before removing the solid-state drive, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on, and
then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see
Back cover on page 36).
5. Remove the tablet battery (see
Tablet battery on page 37).
Remove the solid-state drive:
1. Remove the Phillips PM2.0×3.0 screw (1) that secures the solid-state drive to the system board. (The
solid-state drive tilts up.)
2. Remove the solid-state drive (2) by pulling the drive away from the slot at an angle.
Reverse this procedure to install the solid-state drive.
Removal and replacement procedures 41
