Spare part number Description
NOTE: The card reader board does not include the card reader board cable. The card reader board cable
is included in the Cable Kit, spare part number 742103-001. See
Cable Kit on page 21 for more Cable Kit
spare part information.
736893-001 Volume button board
NOTE: The volume button board does not include the volume button board cable. The volume button
board cable is included in the Cable Kit, spare part number 742103-001. See
Cable Kit on page 21 for
more Cable Kit spare part information.
736899-001 Speaker Kit (includes left and right speakers and cables)
736900-001 Webcamera/microphone module (includes double-sided adhesive and grounding tape)
NOTE: The webcamera/microphone module does not include the webcamera/microphone module
cable. The webcamera/microphone module cable is included in the Cable Kit, spare part number
742103-001. See
Cable Kit on page 21 for more Cable Kit spare part information.
736901-001 Vibrator module (includes cable)
737216-001 Heat sink (includes 3 captive screws and replacement thermal material)
737218-001 128-GB micro-solid-state drive
737696-001 13.3-inch, AG, FHD, WLED TouchScreen, display assembly
NOTE: The display assembly does not include the display panel cable. The display panel cable is
included in the Cable Kit, spare part number 742103-001. See
Cable Kit on page 21 for more Cable Kit
spare part information.
737697-001 13.3-inch, AG, HD, WLED TouchScreen, display assembly
NOTE: The display assembly does not include the display panel cable. The display panel cable is
included in the Cable Kit, spare part number 742103-001. See
Cable Kit on page 21 for more Cable Kit
spare part information.
738259-001 NFC module antenna
738498-001 System board equipped with an Intel Core i3-4012Y 1.50-GHz processor (3.00-MB L3 cache, dual core, 4.5
W), 4-GB of system memory, a graphics subsystem with UMA memory, and the Linux operating system,
but without WWAN capability (includes replacement thermal material)
738498-501 System board equipped with an Intel Core i3-4012Y 1.50-GHz processor (3.00-MB L3 cache, dual core, 4.5
W), 4-GB of system memory, a graphics subsystem with UMA memory, and the Windows 8.1 Standard
operating system, but without WWAN capability (includes replacement thermal material)
738498-601 System board equipped with an Intel Core i3-4012Y 1.50-GHz processor (3.00-MB L3 cache, dual core, 4.5
W), 4-GB of system memory, a graphics subsystem with UMA memory, and the Windows 8.1 Professional
operating system, but without WWAN capability (includes replacement thermal material)
738499-001 System board equipped with an Intel Core i5-4202Y 1.60-GHz processor (3.00-MB L3 cache, dual core, 4.5
W), 4-GB of system memory, a graphics subsystem with UMA memory, and the Linux operating system,
but without WWAN capability (includes replacement thermal material)
738499-501 System board equipped with an Intel Core i5-4202Y 1.60-GHz processor (3.00-MB L3 cache, dual core, 4.5
W), 4-GB of system memory, a graphics subsystem with UMA memory, and the Windows 8.1 Standard
operating system, but without WWAN capability (includes replacement thermal material)
738499-601 System board equipped with an Intel Core i5-4202Y 1.60-GHz processor (3.00-MB L3 cache, dual core, 4.5
W), 4-GB of system memory, a graphics subsystem with UMA memory, and the Windows 8.1 Professional
operating system, but without WWAN capability (includes replacement thermal material)
740187-001 RTC battery (includes cable and double-sided adhesive)
741523-005 2-cell, 18-Wh, 2.45-Ah, Li-ion battery (for use only in the keyboard base, includes cable)
24 Chapter 3 Illustrated parts catalog
