Item Component Spare part number
(1) Display assembly (full hinge-up; includes display panel cable, microphones, hinges, webcam,
and wireless antenna cables and transceivers)
907334-001
(2) Top cover with keyboard (includes keyboard cable and keyboard backlight cable)
NOTE: For a detailed list of keyboard country codes, see Top cover and keyboard on page 47.
907335-xx1
(3) TouchPad 907338-001
(4) TouchPad cable 907332-001
(5) Speakers, front (includes left and right speakers and cables) 907343-001
(6) Speakers, rear (includes left and right speakers and cables) 907344-001
(7) Heat sink (includes replacement thermal material) 907557-001
Fan Kit, includes: 907333-001
(8) Heat sink fan
(9) Rear fan
(10) System board (includes a graphics subsystem with UMA memory and replacement thermal material) equipped with:
Intel Core i7-7500U processor, 16 GB of system memory, and the Windows 10 Professional
operating system
907558-601
Intel Core i7-7500U processor, 16 GB of system memory, and a non-Windows operating system 907558-001
Intel Core i7-7500U processor, 8 GB of system memory, and the Windows 10 Professional operating
system
907559-601
Intel Core i7-7500U processor, 8 GB of system memory, and a non-Windows operating system 907559-001
Intel Core i5-7200U processor, 8 GB of system memory, and the Windows 10 Professional operating
system
907560-601
Intel Core i5-7200U processor, 8 GB of system memory, and a non-Windows operating system 907560-001
Intel Core i5-7200U processor, 4 GB of system memory, and the Windows 10 Professional operating
system
907561-601
Intel Core i5-7200U processor, 4 GB of system memory, and a non-Windows operating system 907561-001
(11) Audio/USB board 907336-001
(12) Audio/USB board cable 907331-001
(13) Power button board 907337-001
(14) Power button board cable 907330-001
(15) RTC battery 907341-001
(16) Solid-state drive (PCIe-3×4, NVMe solid-state drive supporting TLC)
1-TB 865697-001
512-GB 847110-009
256-GB 847109-011
128-GB 912322-002
(17) WLAN module
16 Chapter 3 Illustrated parts catalog
