Speaker, rear left
Description Spare part number
Speaker, rear left (includes cable) 907344-001
Before removing the rear left speaker, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation,
turn the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 22).
5. Disconnect the battery cable from the system board (see Battery on page 24).
Remove the rear left speaker:
1. Disconnect the speaker cable (1) from the system board.
2. Remove the two Phillips PM2.0×3.5 screws (2) that secure the speaker to the computer.
3. Remove the speaker (3).
Reverse this procedure to install the rear left speaker.
30 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
