HP StorageWorks 8/20q User Manual

HP StorageWorks 8/20q and SN6000 Fibre Channel Switch Enterprise Fabric Management Suite User Guide 103
Network IP Security
Network IP Security provides encryption-based security for IP version 4 and IP version 6 communications
through the use of security policies and associations. The security policy database is the set of all security
policies configured on the switch.
To manage IP security associations and policies:
1. Select an entry switch in the fabric tree.
2. Select Switch > Network > Ipsec Properties to open the IPsec Configuration dialog box (Figure 57).
NOTE: The IPsec Configuration dialog box is only available with a secure fabric on the entry switch.
Figure 57 IPsec Configuration dialog box
Table 16 describes the Network IP buttons in the IPsec Configuration dialog box.
Table 16 IPsec Configuration dialog box buttons
Button Description
Add Opens the Create IP Security Association dialog box in which to add a new
IP security association. Opens the Create IP Security Policy dialog box in
which to add a new IP security policy.
Delete Deletes the selected association or policy.
Edit Opens a dialog box in which to change the selected association or policy.
Copy Copies the selected association or policy. This puts the association or policy
into the clipboard. When you paste a copy, it is added to the list.
Paste Pastes an association or policy from the clipboard into the corresponding
database. The newly created associations must be edited to make them
unique.
Export Saves the selected association/policy configuration to an XML file.
Import Imports an association or policy from an XML file.

HP StorageWorks 8/20q Specifications

General

Brand	HP
Model	StorageWorks 8/20q
Category	Switch
Language	English
