HP StorageWorks 8/20q and SN6000 Fibre Channel Switch Enterprise Fabric Management Suite User Guide 91
NOTE: The switch downs a port if a rising trigger alarm is not cleared after three consecutive sample
windows.
Figure 50 Port threshold alarm example
8. Enter a sample window in seconds. The sample window defines the period of time in which to count
events.
9. Repeat steps 3 through 7 for each alarm you want to configure or enable.
10. Click OK to save all changes.
Paging a switch
You can use the Beacon feature to page a switch. The Beacon feature causes all Logged-In LEDs to flash,
making them easier to recognize. To page a switch:
1. Select a switch in the fabric tree.
2. Select Switch > Toggle Beacon.
To cancel the beacon, reselect Toggle Beacon.
Setting the date/time and enabling NTP client
The Date/Time dialog box (Figure 51) enables you to manually set the date, time, and time zone on a
switch, or to enable NTP (Network Time Protocol) Client to synchronize the date and time on the switch
with an NTP server. Enabling the NTP Client, which requires an Ethernet connection to an NTP server,
ensures the consistency of date and time stamps in alarms and log entries. Although the date/time is set or
displayed in the firmware in Universal Time, when displayed in the Date/Time dialog box, the value is
always in local time.
If you select the NTP Client Enabled option (the default is deselected):
• Date and Time areas become active, and you are prevented from manually setting the date and time
on the switch.
• NTP Server Discovery and NTP Server IP Address fields become active, and you can select a discovery
method.
Rising
Trigger
Falling
Trigger
Event
Count
Sample Window
Generate falling
trigger alarm;
eligibility is reset
Generate rising
trigger alarm;
eligibility ends
Generate rising
trigger alarm;
eligibility ends
