HP StorageWorks 8/20q and SN6000 Fibre Channel Switch Enterprise Fabric Management Suite User Guide 85
First Port Address Switch Fibre Channel address
World Wide Name Switch World Wide Name
Serial Number Number assigned to each chassis
Reason for Status Reason for the operational state
Vendor Switch manufacturer
MAC Address Media Access Control address
Negotiated Domain ID Domain ID currently being used by the fabric
Configured Domain ID Domain ID, defined by network administrator
Domain ID Lock Domain ID lock status. Prevents (True) or permits (False) dynamic
domain ID reassignment.
Number of Ports Number of physical ports on the switch
Operational State Switch operational state: Online, Offline, Diagnostic, Down
Administrative State Current switch administrative state
Configured Admin State Administrative state that is stored in the switch configuration
Beacon Status Switch LEDs are blinking (On) or not blinking (Off).
Status Group
Operational State Switch operational state: Online, Offline, Diagnostic, Down
Administrative State Current switch administrative state
Configured Admin State Administrative state that is stored in the switch configuration
Beacon Status Beacon status. Switch LEDs are blinking (On) or not blinking (Off).
Reason for Status Reason for the operational state
Temperature Internal switch temperature °C
Fan 1 Status Fan 1 operational status (dual power supply model only)
Fan 2 Status Fan 2 operational status (dual power supply model only)
Fan 3 Status Not applicable
Power Supply 1 Status Power supply 1 operational status
Power Supply 2 Status Power supply 2 operational status (dual power supply model only)
Temperature Failure Port
Shutdown
Non-configurable (always enabled for this switch). All ports are shut
down when the switch temperature exceeds the Failure Temperature.
Warning Temperature Non-configurable temperature threshold, above which a warning
condition alarm is generated
Failure Temperature Non-configurable temperature threshold, above which a failure
condition alarm is generated
POST Status Current diagnostic state of the switch
POST Fault Code Code value for the last recorded diagnostic test result recorded on the
switch
Test Status Current diagnostic test status of switch
