HP StorageWorks Ultrium 960 - Autoloader Product Overview

88 pages

To Next Page

To Previous Page

Installing the autoloader12

Autoloader product overview

Figure 1 Front panel overview

Figure 2 Rear panel overview

Number Description

1Power switch

2Mailslot

3 Front panel LEDs

4 Front panel LCD screen

5 Control keys

Number Description

1 68-pin HD SCSI connectors

2Fan vent

3 Power connector
