Ultrium 960, Ultrium 448, Ultrium 460, Ultrium 230, DLT VS80, SDLT 320 25
Operator’s panel control buttons
The Operator’s Panel includes four buttons that provide access to all operations and information
menus.
Understanding the menu structure (Ultrium 960 and Ultrium 448)
The Ultrium 960 and Ultrium 448 Tape Autoloaders have an online and an offline mode. You need
to be in Offline mode to access the full menu structure; in Online mode only the Information menu is
available, as illustrated in Figure 11 on page 26. For all other Tape Autoloader models see
”Understanding the menu structure (all other models)” on page 27.
Media Attention Amber Illuminated if the tape drive has detected a cartridge or
tape fault. Recommended action is to export the cartridge
from the autoloader. Doing so turns off the LED. See
”Exporting tape cartridges” on page 30. If a particular
cartridge causes these symptoms repeatedly, that cartridge
may be defective.
Error Red Illuminated if an unrecoverable tape drive or autoloader
error occurs. A corresponding error message displays on
the LCD screen (see ”Autoloader Error Codes” on page 26
for more information).
Table 9 LEDs
LED Color Description
Table 10 Control buttons
Button Description
Cancel Cancels the current menu option and returns to the previous menu level or
Home screen.
Previous Selects the previous item or value in the currently displayed menu.
Next Selects the next item or value in the currently displayed menu.
Enter Executes the current menu or selects the current option displayed on the LCD
panel.
