TouchPad board
NOTE: The TouchPad board spare part kit does not include the TouchPad board cable. The TouchPad board
cable is available using spare part number 830763-001.
Description Spare part number
In ash silver finish for use only on HP Stream 11 Pro G2 Notebook PC computer models 835665-001
In cobalt blue finish for use only on HP Stream Notebook PC computer models 830762-001
In violet purple finish for use only on HP Stream Notebook PC computer models 835663-001
Before removing the TouchPad board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 30).
Remove the TouchPad board:
1. Turn the keyboard/top cover upside down with the front toward you.
2. Remove the four Phillips PM2.0×2.8 screws (1) that secure the TouchPad board bracket
and TouchPad board to the top cover.
3. Remove the three Phillips PM2.0×2.2 broad head screws (2) that secure the TouchPad board to
the top cover.
4. Remove the TouchPad board bracket (3).
Component replacement procedures 35
