Connector board
NOTE: The connector board spare part kit does not include the connector board cable. The connector board
cable is available using spare part number 830759-001.
Description Spare part number
Connector board for use only on HP Stream Notebook PC computer models equipped with WWAN
capability (includes SIM slot and WWAN slot)
830758-001
Connector board for use only on computer models not equipped with WWAN capability (includes audio
jack and USB port)
830801-001
Before removing the connector board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 30).
5. Remove the battery (see Battery on page 39).
6. Remove the WWAN module (select models only, see WWAN module on page 43).
Remove the connector board:
1. Release the ZIF connector (1) to which the connector board cable is attached, and then disconnect
the connector board cable from the system board.
2. Detach the connector board cable (2) from the bottom cover. (The connector board cable is attached to
the bottom cover with double-sided adhesive.)
3. Remove the Philllips PM2.0×3.3 screw (3) that secures the connector board to the bottom cover.
46 Chapter 5 Removal and replacement procedures
