Description Spare part number Description Spare part number
For use in Italy L02776-061 For use in the United States L02776-001
For use in Japan L02776-291
Before removing the keyboard/top cover, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the computer feet (see Computer feet on page 20).
NOTE: When replacing the keyboard/top cover, be sure that the TouchPad board (see TouchPad board
on page 35) and power button board (see Power button board on page 33) are removed from
the defective keyboard/top cover and installed on the replacement keyboard/top cover.
Remove the keyboard/top cover:
1. Remove the ve Phillips PM2.5×8.0 screws (1) and two Phillips PM2.0×5.0 screws (2) that secure
the keyboard/top cover to the bottom cover.
2. Turn the computer right side up with the front toward you.
3. Open the computer as far as it will open.
4. Insert a case utility tool (1) or similar thin, plastic tool between the front edge of the keyboard/top cover
and the bottom cover.
22 Chapter 5 Removal and replacement procedures
