Boards, memory, processors
Item Description Spare part number
(1) Graphics cards (includes bracket; not available in the Americas region)
NOTE: The Americas region offers only integrated graphics; a discrete graphics option
is not available.
AMD Radeon HD 6450A 1GB DDR3 MXM 3.0A 671561-001
AMD Radeon HD 6450A 1GB DDR3 MXM 3.0A 671563-001
NVIDIA GeForce GT 5xx 1GB DDR3 MXM 3.0A 671564-001
NVIDIA GeForce GT 5xx 2GB DDR3 MXM 3.0A 671565-001
(2) Touch controller board 671570-001
(3) Converter 671569-001
(4) WLAN modules
802.11b/g/n (2x2) WLAN card 654602-001
HP WLAN combo 802.11b/g/n + Bluetooth 2.1 card 652279-001
802.11b/g/n (1x1) WLAN module 634906-001
(5) TV tuners
HP Digital TV Tuner Mini PCIe Card (includes TV tuner and hardware kit; non-BFR) 613990-001
HP Digital TV Tuner Mini PCIe Card (includes TV tuner and hardware kit; BFR) 621425-001
HP TV Tuner SW DVB-T Mini Card (for use in EMEA) 671566-001
28 Chapter 6 Illustrated parts catalog
