Processor
Description Spare part number
Intel Core i7 processors
2600S (2.7 GHz, 8-MB L3 cache; not for Brazil) 638419-001
Intel Core i5 processors
2500S (2.7 GHz, 6-MB L3 cache) 638420-001
2400S (3.1-GHz, 6-MB L3 cache) 640953-001
Intel Core i3 processors
2120 (3.3 GHz, 3-MB L3 cache) 638412-001
2105 (3.1 GHz, 3-MB L3 cache) 655970-001
2100 (3.1 GHz, 3-MB L3 cache) 638411-001
Intel Pentium Dual-Core processors
G850 (2.9-GHz, 3-MB L3 cache) 655973-001
G840 (2.8-GHz, 3-MB L3 cache) 655972-001
G620 (2.6-GHz, 3-MB L3 cache) 655971-001
1. Prepare the computer for disassembly (see Preparing to Disassemble the Computer
on page 40).
2. Remove the rear cover (see
Rear Cover on page 41).
3. Remove the system board cover (see
System Board Cover on page 60).
4. Remove the processor heat sink (see
Heat sinks (Thermal Modules) on page 66).
68 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
