HP TouchSmart Elite 7320 User Manual
5
of 1
of 1 rating
157 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
Spare part
number
Description
671594-001
IR blaster cable
671595-001
Hard drive cable
671596-001
Optical drive cable
671597-001
Power button/LED cable
671598-001
LVDS cable
671599-001
Converter cable
671600-001
Touch controller cable
671601-001
TV tuner, RF, PAL, 40mm
Sequential part number li
sting
39
46
48
Table of Contents
Default Chapter
3
About this Book
3
Table of Contents
5
1 Product Features
9
Overview
9
Front Components
11
Side Components
12
Rear Components
13
2 Installing and Customizing the Software
14
Installing the Operating System
14
Downloading Microsoft Windows Updates
14
Installing or Upgrading Device Drivers (Windows Systems)
15
Accessing Disk Image (ISO) Files
15
Protecting the Software
15
3 Computer Setup (F10) Utility
16
Computer Setup (F10) Utilities
16
Using Computer Setup (F10) Utilities
17
Computer Setup-File
18
Computer Setup-Storage
19
Computer Setup-Security
21
Computer Setup-Power
24
Computer Setup-Advanced
25
4 Serial ATA (SATA) Drive Guidelines and Features
26
SATA Hard Drives
26
SATA Hard Drive Cables
26
SATA Data Cable
26
SMART ATA Drives
27
Hard Drive Capacities
27
5 Routine Care and Disassembly Preparation
28
Electrostatic Discharge Information
28
Generating Static
28
Preventing Electrostatic Damage to Equipment
29
Personal Grounding Methods and Equipment
29
Grounding the Work Area
30
Recommended Materials and Equipment
30
Operating Guidelines
31
Routine Care
31
General Cleaning Safety Precautions
31
Cleaning the Computer Case
31
Cleaning the Keyboard
32
Cleaning the Monitor
32
Cleaning the Mouse
33
Service Considerations
33
Tools and Software Requirements
33
Screws
33
Cables and Connectors
33
Hard Drives
34
Lithium Coin Cell Battery
34
6 Illustrated Parts Catalog
35
Computer Major Components
35
Boards, Memory, Processors
36
Mass Storage Devices
37
Cables
38
Misc Parts
39
Keyboards (Not Illustrated)
40
Sequential Part Number Listing
41
7 Removal and Replacement Procedures All-In One (AIO) Chassis
48
Preparing to Disassemble the Computer
48
Rear Cover
49
Stand
50
Memory Cover
51
Memory
53
Optical Drive
55
Hard Drive
57
Converter Board
60
Touch Controller Board
62
Webcam Module
64
Speakers
66
System Board Cover
68
WLAN Module
70
TV Tuner Module
72
Heat Sinks (Thermal Modules)
74
Processor
76
Graphics Card
78
Fan
80
VESA Cover with Kensington Lock Bracket
82
Optical and Hard Drive Cables and Connector
84
Coaxal Cable Connector
86
System Board
88
Display Cable
91
Front Bezel and Display Panel
93
Cable Routing
99
Appendix A Troubleshooting Without Diagnostics
100
Safety and Comfort
100
Before You Call for Technical Support
100
Helpful Hints
101
Solving General Problems
103
Solving Power Problems
106
Solving Diskette Problems
107
Solving Hard Drive Problems
110
Solving Media Card Reader Problems
113
Solving Display Problems
115
Solving Audio Problems
119
Solving Printer Problems
121
Solving Keyboard and Mouse Problems
122
Solving Hardware Installation Problems
124
Solving Network Problems
125
Solving Memory Problems
129
Solving Processor Problems
130
Solving CD-ROM and DVD Problems
131
Solving USB Flash Drive Problems
133
Solving Front Panel Component Problems
134
Solving Internet Access Problems
134
Solving Software Problems
137
Contacting Customer Support
138
Appendix B POST Error Messages
139
POST Numeric Codes and Text Messages
140
Interpreting POST Diagnostic Front Panel Leds and Audible Codes
147
Appendix C Connector Pin Assignments
150
Ethernet BNC
150
Usb
150
Microphone
150
Headphone
151
Line-In Audio
151
Line-Out Audio
151
Appendix D Power Cord Set Requirements
152
General Requirements
152
Japanese Power Cord Requirements
152
Country-Specific Requirements
153
Appendix E Specifications
154
All-In One Models
154
Index
155
