4. Insert a screwdriver into the slot next to the drive bracket (2) and push the drive out of the bay,
and then slide the drive out of the computer (3).
Figure 7-7 Removing the optical drive
5. If you need to remove the drive bracket from the drive, remove the two Torx screws (1) that
secure the bracket to the drive, and then remove the bracket from the drive (2).
NOTE: Optical drive spare part kits do not include replacement brackets. Reuse the existing
bracket.
Figure 7-8 Removing the optical drive bracket
To install an optical drive, reverse the removal procedures.
48 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
