5. Slide the hard drive out of the cage (2).
Figure 7-11 Removing the hard drive from the cage
NOTE: Be sure to correctly install the rubber grommets in the HDD cage. Incorrect installation can
result in hard drive installation problems.
To replace the hard drive, reverse the removal procedures.
Hard Drive 51
