4. Remove the 4 Torx screws (1) that secure the cable cover to the computer.
NOTE: The Kensington lock bracket (2) is connected to the VESA cover. You cannot remove
the bracket from the cover. You must replace the entire VESA cover to replace the Kensington
Lock bracket.
Figure 7-42 Removing the VESA cover screws
5. Lift the cover off the computer.
Figure 7-43 Removing the VESA cover
To replace the VESA cover, reverse the removal procedures.
VESA Cover with Kensington Lock Bracket 75
