INDICATION DESCRIPTION LED BEEPER
Label Programming Mode
Acceptance of Partial Label
In cases where multiple
labels must be scanned to
program one feature, this
indication acknowledges
each portion as it is
successfully scanned.
N/A Scanner sounds one short
beep at highest frequency
and current volume.
Label Programming Mode
Acceptance of Programming
Configuration option(s) have
been successfully
programmed via labels and
the scanner has exited
Programming Mode.
N/A Scanner sounds one high
frequency beep and 4 low
frequency beeps followed by
reset beeps.
Label Programming Mode
Cancel Item Entry
Cancel label has been
scanned.
N/A Scanner sounds two times at
low frequency and current
volume.
Error Codes
Upon startup, if the scanner sounds a long tone, this means the scanner has not passed its automatic
Selftest and has entered FRU (Field Replaceable Unit) isolation mode. If the scanner is reset, the
sequence will be repeated.
The following table describes the LED flashes/beep codes associated with an error found.
Number of LED Flashes/Beeps Error Corrective Action
1 Configuration Contact Help desk for assistance
2 Interface PCB Contact Help desk for assistance
6 Digital PCB Contact Help desk for assistance
12 Imager Contact Help desk for assistance
15 Accelerometer Contact Help desk for assistance
Error Codes 31
