c. Use the two Phillips screws to secure the half-height bracket to the drive (2).

3. Align the connectors on the PCIe drive with the socket on the system board and install the drive into the

socket.

NOTE: The drive may be used only in the PCIe slot 4.

Installing the drive in an HP Z230 SFF Workstation 7
