4. Rotate the PCI retention clamp down over the PCI bulkhead.
Installing the drive in an HP Z420 or HP Z440 Workstation
NOTE: If more than one HP Z Turbo Drive is installed in a workstation, the J2 jumper on one of the drives (1)
must be moved to the other position (2).
Eight drives can be identified uniquely with the three jumpers, and all drives in the workstation must be
unique.
The HP Z420 and HP Z440 support two drives only.
1. Press down on the two green PCI retention clips (1) located inside the workstation until they release,
and then rotate them down to raise the retention clamp (2).
8 HP Z Turbo Drive installation
