Chassis components
Component Description Component Description
1 Processor (CPU) heat sink 9 Hard drive carrier, 2.5 inch
2 Graphics card heat sink 10 Hard drive, 2.5 inch
3 Webcam 11 Rear cover
4 Graphics card 12 Memory modules (SODIMMs)
5 System board 13 Fan
6 Power supply 14 Fan
7 M.2 card 15 Chassis and display assembly
8 Speakers 16 Stand
