HP Z1 G3 User Manual

HP Z1 G3 Workstation
●
Supports Intel HD Graphics 530 (Core processors) or Intel HD Graphics P530 (Xeon
processors)
NOTE: If an MXM graphics card is installed, Intel HD Graphics is disabled.
NOTE: Intel HD graphics can drive up to 3 displays simultaneously. For example, it can
drive the internal display and a monitor attached to the external DisplayPort and a monitor
attached to the Thunderbolt 3 port.
I/O technology
●
RAID congurations for SATA RAID levels 0, 1
●
6x USB 3.0 ports
●
Supports European Union ERP Lot 6 tier2 power limit of less than 0.5W in o mode
●
RJ-45 for LAN
●
DisplayPort Out
●
Fixed angle webcam
●
Digital microphone array
●
Audio/headset jack
●
Line in jack (retaskable)
●
SD 4.0 card reader
●
Integrated 2x Thunderbolt/USB 3.1 Type C
●
WLAN and Bluetooth module
●
2x 6 Gbps SATA ports
●
2x M.2, Socket 3, Key M connectors for PCIe G3x4 (module sizes 2242-D5-M, 2260-D5-M,
2280-D5-M)
8 Chapter 1 Hardware overview

HP Z1 G3 Specifications

General

Brand	HP
Model	Z1 G3
Category	Desktop
Language	English
