HP Z1 User Manual

Product information
Table 1-1 Product information
Topic Location
Technical specifications Go to
www.hp.com/go/quickspecs. In the left pane, select your region and then
select Workstations.
HP Cool Tools (Windows® 7
only)
Most HP workstations with the Windows 7 operating system are preloaded with tools
that may enhance system performance and with additional software that is not
automatically installed during first boot. To access these applications:
●
Click the HP Cool Tools icon on the desktop, or
●
Open the HP Cool Tools folder by selecting Start > All Programs > HP >
HP Cool Tools.
To learn more about these applications, click HP Cool Tools—Learn More.
To install or launch the applications, click the appropriate application icon.
Regulatory information Refer to the Safety & Regulatory Information guide for product regulatory information.
You can also refer to the regulatory label on the workstation chassis.
Accessories For complete and current information on supported accessories and components, see
http://www.hp.com/go/workstations.
System board A diagram of the system board is located on the inside of the chassis (all-in-one
configuration). Additional information is located in the workstation Maintenance and
Service Guide on the Web at
http://www.hp.com/support/workstation_manuals/.
Serial number, Certificate of
Authenticity (COA), and Genuine
Microsoft Label (GML) (if
applicable)
The serial number label is on a pull-out card on the side of the display (all-in-one
configuration). The COA (Windows 7) and GML (Windows 8) are typically located
near the serial number label. Some workstations have this label on the bottom panel.
Linux For information on running Linux on HP workstations, go to
http://www.hp.com/
linux/, then select Linux on Workstations from the list on the left.
2Chapter 1 Locating HP resources

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
