HP Z1 User Manual

Adjusting the audio signal
●
There is no hardware volume control on the HP Z1 Workstation. (However, some keyboards do
have volume buttons, usually in the upper-right corner.)
●
Volume can be adjusted with the operating system (OS) master control or the software (SW) audio
player control.
●
The OS master control and SW audio player control are independent. However, they are both
simultaneously active and affect the overall volume of the audio signal.
●
If the audio signal is not audible, check the OS master control and SW audio player control to be
sure that neither is set too low.
Using the webcam
The webcam works automatically with any webcam software.
A white activity LED is on when the webcam is active. Optimal performance of the fixed-focus lens is at
0.5 meters.
A dial at the top of the workstation lets you:
●
Adjust the camera angle.
●
Disable the camera by turning the dial all the way toward the front of the workstation. A red stripe
in the camera viewport indicates the lens is pointing straight down into the chassis. The user is not
visible.
Installing optional components
You can install additional components such as memory, hard drives, and PCIe Mini Cards in your
workstation.
●
To view component installation videos, go to
http://www.hp.com/go/sml.
●
For installation guidelines and technical information, refer to the HP Z1 Workstation Maintenance
and Service Guide at
http://www.hp.com/support/workstation_manuals.
Security
You can secure your workstation by attaching a lock to the cable lock slot. The workstation includes
several security features to reduce the risk of theft and to warn of chassis intrusion. Refer to the
Maintenance and Service Guide for information about additional hardware and software security
features available for your system.
Product recycling
HP encourages customers to recycle used electronic hardware, HP original print cartridges, and
rechargeable batteries.
24 Chapter 3 Setting up and using the workstation

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
