HP Z1 User Manual

HPIKL driver disc
Recent versions of Red Hat Linux typically require only driver updates with minor fixes to support HP
workstations. These releases can usually be supported with the HPIKL driver disc, which can be used as
a post-installation utility for the standard Red Hat Linux install.
After you complete the standard Red Hat install and restart the system, a Red Hat first-boot utility runs.
After you specify a number of settings (such as the security level, time and date, root password, user
accounts), the utility lets you to load additional disc.
The driver disc is used during this phase. All content added by HP is in the /HP directory on the disc.
You can use it to build your own image or to browse the HP content.
NOTE: Some installations may encounter problems if they are performed with a DisplayPort
connection to the monitor. This is because the default drivers that the OS installers use do not support
DisplayPort functionality. If you experience problems, try overriding the monitor choice for DisplayPort
during the start of the install and using the VESA driver instead. You can then set up the DisplayPort
monitor later.
Installing with the HP Red Hat Linux driver disc
1. If you do not have the appropriate HP driver disc for a supported stream, create one (see HP
Installer Kit for Linux (HPIKL) on page 39.)
2. Install the operating system using the optical media included in the Red Hat Linux box-set.
3. If you have a Red Hat driver disk for the OS version you are installing, enter linux dd on the
initial install splash screen, and then press Enter.
4. When asked if you have a driver disc, select Yes. Place the Red Hat driver disc in the drive, and
select the appropriate drive:hd[abcd]. Continue the normal installation.
5. After successfully installing the operating system, reboot the workstation.
●
RHEL 5: the Red Hat Setup Agent (also known as first-boot) automatically starts. At the
Additional DVDs screen, insert your HP driver disc and select Install. When the driver
installation task is completed, continue following the prompts until the operating system is
successfully installed.
●
RHEL 6: Insert your HP driver disc. The HPIKL installation software automatically starts. Follow
the prompts to install the contents.
Warranty
As part of the HP workstation hardware warranty, HP provides software configuration and installation
support for certified versions of Red Hat Linux for up to 90 days from date of purchase.
40 Chapter 6 Setting up and restoring Linux

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
