Page #51 background imageLoading...
Page #51 background image
7 Updating the workstation
HP is constantly working on improving your total workstation experience. To ensure that the workstation
leverages the latest enhancements, HP recommends that you install the latest BIOS, driver, and software
updates on a regular basis.
Updating the workstation after first boot
After successfully booting the workstation for the first time, you should follow these guidelines to ensure
that the workstation is up-to-date:
Ensure that you have the latest system BIOS loaded. See
Upgrading the BIOS on page 43.
Ensure that you have the latest drivers for your system. See
Upgrading device drivers
on page 44.
Become familiar with your available HP resources.
Consider a subscription to Driver Alerts at
http://www.hp.com/go/subscriberschoice.
Upgrading the BIOS
For optimum performance, determine the BIOS revision on the workstation, and upgrade it if necessary.
Determining the current BIOS version
To determine the current BIOS version:
1. Press Esc during power-up.
2. Press F10 to enter the F10 Setup utility.
3. Select File > System Information. Note the workstation BIOS version and compare it with the
BIOS versions that appear on the HP website.
NOTE: Procedures for upgrading the BIOS, as well as the F10 Computer Setup utility BIOS
Menu settings, are located in the HP Z1 Workstation Maintenance and Service Guide at
http://www.hp.com/support/workstation_manuals.
Updating the workstation after first boot
43

Table of Contents

Other manuals for HP Z1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Z1 and is the answer not in the manual?

HP Z1 Specifications

General IconGeneral
Tcase72.6 °C
Bus typeDMI
SteppingD2
FSB ParityNo
Processor cache8 MB
Processor cores4
Processor modelE3-1245
System bus rate5 GT/s
Processor seriesIntel Xeon E3-1200
Processor socketLGA 1155 (Socket H2)
Processor threads8
Processor codenameSandy Bridge
Processor frequency3.3 GHz
Processor cache typeSmart Cache
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency3.7 GHz
Processor operating modes64-bit
ECC supported by processorYes
Thermal Design Power (TDP)95 W
Number of processors installed1
CPU multiplier (bus/core ratio)33
Maximum number of PCI Express lanes20
Memory types supported by processorDDR3-SDRAM
Memory clock speeds supported by processor1066, 1333 MHz
Memory bandwidth supported by processor (max)21 GB/s
Maximum internal memory supported by processor32 GB
Audio systemHD
Product typeWorkstation
Motherboard chipsetIntel® C206
Memory slots4x DIMM
Internal memory4 GB
Memory channelsDual-channel
Memory clock speed1600 MHz
Memory layout (slots x size)- GB
Resolution2560 x 1440 pixels
Graphics cardQuadro 500M
Networking featuresGigabit Ethernet (10/100/1000)
Wireless technology802.11 a/g/n
Graphics card familyNVIDIA
Maximum storage capacity2 TB
HDD speed7200 RPM
RAID levels0, 1
HDD capacity1000 GB
HDD interfaceSATA
Optical drive typeDVD Super Multi
Maximum graphics card memory1.024 GB
On-board graphics card modelIntel® HD Graphics P3000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency850 MHz
On-board graphics card dynamic frequency (max)1350 MHz
Number of displays supported (on-board graphics)2
Display diagonal27 \
Display number of colors1.073 billion colors
Modem (RJ-11) ports0
USB 2.0 ports quantity7
Bundled softwareRoxio Easy Media Creator; Intervideo WinDVD
Operating system installedWindows 7 Professional
Power supply400 W
Power supply input voltage100 - 240 V
Power supply input frequency50 - 60 Hz
CertificationEnergy Star
Product colorBlack
Country of originChina
Processor codeSR00L
Processor ARK ID52274
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth419.1 mm
Width660.4 mm
Height584.2 mm
Weight213.2 g
